Pallet Tainer
Introducing the pallet tainer – a modular and nestable storage solution with many advantages! This product is ideal for use in warehouses, retail industry, and more. It offers great features that make it highly convenient and cost-effective for your business.
It is fully movable by forklift, allowing you to bring items across the warehouse with ease. The nestable feature also allows you to effectively save your valuable space when not in use. Moreover, its strong structure gives it a very high resistance to earthquakes which makes it ideal even for locations with seismic activity. Not only is the Nestainer Rack easy to move and nestable, but it is also made of premium quality materials (mild steel Q235) giving it superior strength and durability – ensuring a long lasting service life for your storage needs! Its open design makes bulk storing of goods easier as you can access each layer directly from above or below. Additionally, this allows quick picking of items too making it convenient for any level of operation.
Exterior Dimension: 1300Lx1200Wx1200H (mm)
Loading Capacity: 1000 kg
Stacking: 4 high
Loaded in 1x40'HQ: 160 sets
Finish: Powder coating
MOQ: 50 sets
Type: Detachable
Description
Technical Parameters
Video
What is a nestainer?
YST Logistics Equipment's factory show
Customer Case: How to deal with goods damage？
Products Description
Detachable:
Assembly and installation are relatively free and can flexibly respond to changes in the warehouse layout.
Undetachable:
It does not need to be assembled in the warehouse, and it can be used immediately if there is a forklift.
Stackable and nestable:
By using nestainers, you can make effective use of warehouse space.
Resistant to earthquakes:
The triangular rail-on-rail system boasts high damping properties.
Choice of surface treatment
Powder coating - for environment with normal to moderate temperatures and humidity levels. It offers excellent resistance to scratch, abrasion, chemicals, and everyday wear-and-tear.
Hot-dip galvanizing - for products that need to withstand moisture, salt spray, and other corrosive elements. It's a great option for exposed post pallets in many indoor and outdoor applications.
Size
|
Model No. |
Exterior Dimension L x W x H (mm) |
Interior Dimension L x W x H (mm) |
Loading capacity Kg |
Stackability High |
Loaded in 1x40'HQ sets |
| YST-N1 |
1300x1200x1200 |
1200x1150x1000 |
1000 | 4 | 160 |
| YST-N2 |
1300x1200x1400 |
1200x1150x1200 | 1000 | 4 | 160 |
| YST-N3 |
1400x1200x1200 |
1300x1150x1000 |
1000 | 4 | 160 |
| YST-N4 |
1400x1200x1400 |
1300x1150x1200 |
1000 | 4 | 160 |
| YST-N5 |
1500x1200x1200 |
1400x1150x1000 |
1000 | 4 | 160 |
| YST-N6 |
1500x1200x1400 |
1400x1150x1200 |
1000 | 4 | 160 |
| YST-N7 |
1600x1200x1200 |
1500x1150x1000 |
1000 | 4 | 160 |
| YST-N8 |
1600x1200x1400 |
1500x1150x1200 |
1000 | 4 | 160 |
Customzied On demand
Wire mesh guard (side detachable/ back fixed)
It is an option that prevents small items and products from collapsing. It can also be installed on the front.
Central pillar (side detachable/ back fixed)
It is an option that suppresses the falling of unstable loads such as flexible container bags. It is also possible to increase the pillar quantity.
Anti-roll bar (side detachable /back fixed)
It is an option that suppresses the fall of the load. It is possible to increase the number of bars.
Forklift guide
It is an option to move the load safely. It can also be installed on the back side.
Intermediate shelf (detachable)
Two pallets can be stored in one unit, enabling efficient storage.
Bottom steel plate
You can choose the material of the bottom plate from plywood and iron plate. Drilling is also possible.
Different Types
Benefits of Different Types
Normal type
- You can use a forklift to move the Nestainer racks with your items.
- There is no need to unload the cargo when changing the layout of the warehouse, and it can be loaded directly onto the truck.
Reverse type
- One Nestainer can store two pallets. For example, if you stack two Reverse Nestainers, you can store three levels of items.
- In addition, reverse pallet nestainers are recommended for warehouses with low ceilings because they are lower than "normal Nestainers" when stacked in 2 to 4 layers.
Rail type
- A rail-on-rail method that slides the rail at the bottom of the main unit and the rail at the top.
- We are proud of high damping characteristics by rail-on-rail system of three corners.
Pin type
- Compared to the rail type, it leads to an improvement in the number of items that can be stored.
- Since there is no rail, the weight is light and it is excellent in cost merit.
- Because the joint is a pin, it is easier to detachable than the rail type.
Application
Food
Logistics
Agriculture
Warehouse
Transportation
Auto parts(tire)
Packaging
Textile industry
Chemical,etc.
QC
Strict quality control is essential for post pallets. That's why numerous steps are taken during the pallet tainer quality inspection process which includes Sample Confirmation, Raw Material inspection, Component inspection, Semi-finished Product inspection, Finished Product inspection, Packaging inspection and Container inspection. Every stage is monitored carefully to ensure that only rack of the qualified standard are sent out for delivery. This allows customers to feel secure in the knowledge that nestainer you receive will meet your individual needs as well as comply with all safety regulations.
 |
 |
Why Choose Us
Remote Installation Guidance
We provide comprehensive remote after-sales guidance and support in the form of installation videos and online guidance. This allows customers to access the pallet tainer with ease and ensure a smooth post-purchase experience.
Samples Available
YST Logistics Equipment offers professionals a comprehensive one-stop service to streamline the processes and maximize efficiency. We provide material handling solutions, top-quality product manufacturing, functional testing and customs clearance, etc. with the utmost precision. From start to finish our team of experts will be there to ensure that the products you need, get done on time and perfectly.
